BASES

209 Dual Threaded Base

A cast base threaded for mounting on horizontal or vertical surfaces using screws, 1/4 ” bolts, 1/4 ” drive-in anchors, or an adhesive.  Bolt tension cap can be turned so cables can run horizontal or vertical.  Furnished for point sizes 3/8” and 1/2". Specify when ordering.  – UL Listed

A209       Aluminum

C209       Bronze

C209L  Lead Coated Bronze

210 Top Mount Base

A cast base threaded for mounting on horizontal surfaces using screws, 1/4 ” bolts, 1/4 ” drive-in anchors, or an adhesive.  Bolt tension cap can be turned so cables can run horizontal or vertical.  Furnished for all point sizes 3/8”, 1/2", and 5/8”. Specify when ordering.  – UL Listed

A210       Aluminum

C210       Bronze

C210L  Lead Coated Bronze

211 Side Mount Base

A cast base threaded for mounting on vertical surfaces using screws, 1/4 ” bolts, or 1/4 ” drive-in anchors.  Bolt tension cap can be turned so cables can run horizontal or vertical.  Furnished for all point sizes 3/8”, 1/2", and 5/8”. Specify when ordering.  – UL Listed

A211       Aluminum

C211       Bronze

C211L  Lead Coated Bronze

216 Universal Swivel Base

This is the most universal base in the industry.  The swivel adaptor allows the point to level under most conditions.  It can be secured with screws, nails, 1/4" bolts, 1/4" drive-in anchors, or an adhesive.  Bolt tension cap can be turned so the cable can run horizontal or vertical.  Perfect for skylights, domed or gently sloping roofs, or any uneven surface.  Furnished for all points – 3/8”, 1/2", and 5/8”.  Specify when ordering.  UL Listed.

A216       Aluminum

C216       Bronze

C216L  Lead Coated Bronze

218 Offset Base

A cast base with a 2” offset to clear an overhang when mounted on a vertical surface using screws, 1/4 ” bolts, or 1/4 ” drive-in anchors.  Bolt tension cap can be turned so cables can run horizontal or vertical.  Furnished for all point sizes 3/8”, 1/2", and 5/8”. Specify when ordering.  – UL Listed

A218       Aluminum

C218       Bronze

C218L  Lead Coated Bronze

220 Adhesive Base

This base has bolt tension cable clamping and can be used on any surface with an adhesive.  Furnished for all point sizes 3/8”, 1/2", and 5/8”. Specify when ordering.  – UL Listed

A220       Aluminum

C220       Bronze

C220L  Lead Coated Bronze

222 Side Mount Base

This cast base has bolt tension cable clamping and can be mounted vertically with screws, 1/4 ” bolts, or 1/4 ” drive-in anchors.  Furnished for point sizes 3/8”, 1/2", and 5/8”. Specify when ordering.  – UL Listed

A222       Aluminum

C222       Bronze

C222L  Lead Coated Bronze

224 Top Mount Base

This cast base can be mounted horizontally with screws, 1/4 ” bolts, or 1/4 ” drive-in anchors.  Bolt tension cap can be turned so cables can run horizontal or vertical.  Furnished for all point sizes 3/8”, 1/2", and 5/8”. Specify when ordering.  – UL Listed

A224       Aluminum

C224       Bronze

C224L  Lead Coated Bronze

225 Side Mount Base

This cast base can be mounted vertically with screws, 1/4 ” bolts, or 1/4 ” drive-in anchors.  Bolt tension cap can be turned so cables can run horizontal or vertical.  Furnished for all point sizes 3/8”, 1/2", and 5/8”. Specify when ordering.  – UL Listed

A225       Aluminum

C225       Bronze

C225L   Lead Coated Bronze

227 Top Mount Base

This cast base has bolt tension cable clamping and can be mounted horizontally with screws, 1/4 ” bolts, or 1/4 ” drive-in anchors.  Furnished for point sizes 3/8”, 1/2", and 5/8”. Specify when ordering.  – UL Listed

A227       Aluminum

C227       Bronze

C227L  Lead Coated Bronze

228 Narrow Surface Base

This strap aluminum or copper base can be mounted on a narrow surface or ridge roof with screws or nails.  Base can be modified to accept other anchors.  Compression type fingers crimp over cable for easy installation.  Available for Class I structures only.  Furnished for point sizes – 3/8” and 1/2".  Specify when ordering.

A228       Aluminum

C228       Copper

C228L  Lead Coated Copper

229 Narrow Surface Base

This strap aluminum or copper base can be mounted on a narrow surface or ridge roof with screws or nails.  Base can be modified to accept other anchors.  Bolt tension cap provides maximum cable support.  Furnished for point sizes – 3/8”, 1/2", and 5/8”.  Specify when ordering.  UL Listed.

A229       Aluminum

C229       Copper

C229L  Lead Coated Copper

230 Ridge Mount Base

This strap aluminum or copper base can be mounted on a ridge roof with screws or nails.  Base can be modified to accept other anchors.  Compression type fingers crimp over cable for easy installation.  Available for Class I structures only.  Furnished for point sizes – 3/8” and 1/2".  Specify when ordering.

A230       Aluminum

C230       Copper

C230L  Lead Coated Copper

231 Ridge Mount Base

This strap aluminum or copper base can be mounted on ridge roof with screws or nails.  Base can be modified to accept other anchors.  Bolt tension cap provides maximum cable support.  Furnished for point sizes – 3/8”, 1/2", and 5/8”.  Specify when ordering.  UL Listed.

A231       Aluminum

C231       Copper

C231L  Lead Coated Copper

232 Cast Ridge Base

This cast aluminum or copper base can be mounted on a ridge roof with screws or nails.  Cast with a soft alloy so it can easily form to the ridge.  The base can be modified to accept other anchors.  Compression type fingers crimp over cable for easy installation.  Available for Class I structures only.  Furnished for point sizes – 3/8” and 1/2".  Specify when ordering.   UL Listed.

A232       Aluminum

C232       Brass

C232L  Lead Coated Brass

C233 Cast Ridge Base

This cast aluminum or copper base can be mounted on ridge roof with screws or nails.  Cast with a soft alloy so it can easily form to the ridge. This base can be modified to accept other anchors.  Bolt tension cap provides maximum cable support.  Furnished for point sizes – 3/8”, 1/2", and 5/8”.  Specify when ordering.  UL Listed.

A233       Aluminum

C233       Brass

C233L  Lead Coated Brass

235 Cast Straight Base

Cast aluminum or bronze straight base.  Two set screws hold cable firmly and point screws into top to keep cable and point in straight line.  Available for point sizes 3/8” and 1/2".  Specify when ordering.  UL Listed.

A235       Aluminum

C235       Bronze

C235L  Lead Coated Bronze

237 Standing Seam Base

Base for standing seam roof has 3/4" groove to fit over most seams.  Provided with a swivel adapter for leveling points.  Cable holder is adjustable so cables can run parallel or perpendicular.  Two set screws secure base to seam.  Available for point sizes 3/8”, 1/2", and 5/8”.  Specify when ordering.  UL Listed.

A237       Aluminum

C237       Bronze

C237L  Lead Coated Bronze

Cast aluminum or bronze pipe bases.  Base can be drilled for top mounting or side mounting on most pipes.  Base sizes range from 1.314” to 1.900” and 1.750” to 2.500” Each base is numbered for easy ordering.  Available for point sizes 3/8”, 1/2", and 5/8”.  Specify when ordering.  UL Listed.

Top Mount Base With 1.314” to 1.900” Range

A240       Aluminum

C240       Bronze

C240L  Lead Coated Bronze

Side Mount Base With 1.314” to 1.900” Range

A241       Aluminum

C241       Bronze

C241L  Lead Coated Bronze

Top Mount Base With 1.750” to 2.500” Range

A242       Aluminum

C242       Bronze

C242L  Lead Coated Bronze

Side Mount Base With 1.750” to 2.500” Range

A243       Aluminum

C243       Bronze

C243L  Lead Coated Bronze

250       Stamped Vent Base

Stamped aluminum or copper vent point base with no cable holder.  Over 8 square inches of contact to direct mount air terminal on continuous metal surface.  Furnished for all point sizes 3/8”, 1/2", and 5/8”.  Specify when ordering.  UL Listed

A250        Aluminum

C250        Copper

C250L   Lead Coated Copper

252 Cast Point Base

Cast aluminum or bronze vent point base with no cable holder.  Over 8 square inches of contact to direct mount air terminal on continuous metal surface.  Furnished for all point sizes 3/8”, 1/2", and 5/8”.  Specify when ordering.  UL Listed

A252        Aluminum

C252        Bronze

C252L   Lead Coated Bronze
